CKJPF90/SC船用电缆应用范围:
交联聚乙烯绝缘聚烯烃内护套裸镀锡铜丝编织铠装低烟无卤阻燃船用控制电缆 SC型适用于船舶及舰船电信、电子计算机、电力传输和控制系统,可广泛用于对化工、电力、冶炼等同样使用。
电缆结构:
产品型号:CKJPF90/SC船用电缆
产品简称:镀锡钢丝编织铠装SC型船用控制电缆
导体材料:多股镀锡铜丝
绝缘材料:辐照交联聚乙烯 芯线颜色:五芯红黄绿蓝黑,多芯黑色编码
内护套材料:交联聚烯烃
屏蔽材料:镀锡铜丝编织铠装
外护套材料:低烟无卤交联聚烯烃外护套
结 构:圆形结构,颜色黑色
印字要求:电缆外护套表面印:厂名,型号,规格,电压,米标。
型号说明:
CKJPF80/SC | 交联聚乙烯绝缘聚烯烃内护套裸镀锡铜丝编织铠装低烟无卤阻燃船用控制电缆 SC型 |
CKJPF90/SC | 交联聚乙烯绝缘聚烯烃内护套裸镀锌钢丝编织铠装低烟无卤阻燃船用控制电缆 SC型 |
CKJPF80/NC | 交联聚乙烯绝缘聚烯烃内护套裸镀锡铜丝编织铠装耐火船用控制电缆 NC型 |
CKJPF90/NC | 交联聚乙烯绝缘聚烯烃内护套裸镀锌钢丝编织铠装耐火船用控制电缆 NC型 |
技术参数:
标准:IEC 60228/IEC60092-375/IEC60092-351/ IEC60092-359/ IEC60332/ IEC60331
工作电压:150/250V
出厂测试电压:5KV
***小弯曲半径:电缆外径*8倍
长期工作温度应不高于+85℃
长期工作温度应不低于-20℃
规格选型:
CKJPF90/SC-150/250V-5*1.0 | CKJPF90/SC-150/250V-5*1.5 | CKJPF90/SC-150/250V-5*2.5 |
CKJPF90/SC-150/250V-7*1.0 | CKJPF90/SC-150/250V-7*1.5 | CKJPF90/SC-150/250V-7*2.5 |
CKJPF90/SC-150/250V-10*1.0 | CKJPF90/SC-150/250V-10*1.5 | CKJPF90/SC-150/250V-10*2.5 |
CKJPF90/SC-150/250V-12*1.0 | CKJPF90/SC-150/250V-12*1.5 | CKJPF90/SC-150/250V-12*2.5 |
CKJPF90/SC-150/250V-14*1.0 | CKJPF90/SC-150/250V-14*1.5 | CKJPF90/SC-150/250V-14*2.5 |
CKJPF90/SC-150/250V-19*1.0 | CKJPF90/SC-150/250V-19*1.5 | CKJPF90/SC-150/250V-19*2.5 |
CKJPF90/SC-150/250V-24*1.0 | CKJPF90/SC-150/250V-24*1.5 | CKJPF90/SC-150/250V-24*2.5 |
CKJPF90/SC-150/250V-27*1.0 | CKJPF90/SC-150/250V-27*1.5 | CKJPF90/SC-150/250V-27*2.5 |
CKJPF90/SC-150/250V-30*1.0 | CKJPF90/SC-150/250V-30*1.5 | CKJPF90/SC-150/250V-30*2.5 |
CKJPF90/SC-150/250V-33*1.0 | CKJPF90/SC-150/250V-33*1.5 | CKJPF90/SC-150/250V-32*2.5 |
CKJPF90/SC-150/250V-37*1.0 | CKJPF90/SC-150/250V-37*1.5 | CKJPF90/SC-150/250V-37*2.5 |
